The membrane filtration product of Jintai Company is a kind of surface filtration. The surface of this product has a very thin precision filter layer, and the inside is a high-strength support layer. The two layers are sintered at high temperature to form a chemical bond, so the filter layer will not fall off even under harsh working conditions. The Jintai membrane filtration product has low pressure loss during filtration and has a good anti-cleaning effect, which can greatly extend the service life of the filter element.
Surface filtration
Lower pressure difference
Good regeneration performance
Longer service life
| Material selection | Stainless steel: 316L 304L Other materials required by the customer |
| Filtration Grade | 0.1um 0.3um 0.5um 1um 3um Other grade required by the customer |
| Data & Specifications | Length: The longest seamless tube is 1600mm Diameter: 25-64mm Other specifications and sizes required by customers |
| Connection | Thread, flange, flat pressing, quick connection, etc. Other ways required by customers |
Typical Application
Impurity filtration and precision filtration of petrochemical products
Filtration and recovery of crystals and catalysts, solvent recovery
Gas-solid separation, solid-liquid separation in high temperature and corrosive conditions
Gas purification
Sterilization and filtration in medicine and other fields
